News and Agenda Archive

News

BSc Group at ELCA awarded with IEEE Best High Tech Start-up Business Plan

At the Bachelor Electrical Engineering Graduation Grand Finale held on 7 July 2017, the six-student group formed by Bilal Bouazzata, Laurens Buijs, Jun Feng, Martijn Hoogelander, Alexander Louwerse and Niels van der Kolk received the IEEE Best High Tech Start-up Business Plan award from Koen Bertels for their business plan on the topic of their graduation project at ELCA.

The group was supervised by Marco Pelk and Morteza Alavi while the project was proposed by Leo de Vreede.

During this project, the group accomplished a proof of concept for a promising "interpolating-supply" power amplifier efficiency enhancement technique, laying a foundation for future research.


Best student paper award VLSI Symposium for PhD Bahman Yousefzadeh

At the 2017 VLSI Symposium, Bahman Yousefzadeh received the 2016 best student paper award! The award was for the design of a CMOS temperature sensor with record-breaking inaccuracy of less than +/-0.06 °C over a wide temperature range (-70 °C to 125 °C). Saleh Heidary and Kofi Makinwa were co-authors, and the work was done in collaboration with NXP Semiconductors. The resulting journal paper can be found in the here.


Four papers at VLSI 2017!

Members of the EI lab will present four papers at the 2017 VLSI Circuits Symposium in Kyoto, Japan! The papers are about multi-function sensor interfaces, resistor-based temperature sensors, eddy-current displacement sensors and precision amplifiers, respectively.


Kofi is the Analog Subcom Chair of ISSCC!

The ISSCC (International Solid-State Circuits Conference) is the premier forum for presenting advances in integrated circuit design


Burak wins 1st prize in the SSCS Benelux Chapter's Student Chip Design Contest!

Burak Gonen won 1st prize in the Student Chip Design Competition organized by the Benelux Chapter of the IEEE Solid-State Circuits Society (SSCS). He received the award for the design of "A Dynamic Zoom ADC with 109-dB DR for Audio Applications." The ADC, developed in collaboration with NXP, achieves state-ot-the-art performance in terms of both its area and energy efficiency.

To recognize the excellence and to promote chip design in Benelux region, the IEEE Solid State Circuits Society Benelux Chapter organized a chip design contest for students. The Award includes 750€ as well as a travel grant up to 1000€ for Advances in Analog Circuit Design Workshop (AACD) or European Solid State Circuits Conference (ESSCIRC). The awards will be given in a workshop at TU Delft in spring 2017 together with the award winners' presentations and other technical talks about chip design research in TU Delft.

More ...


Kofi Makinwa in BNR radio show about the influence of computer chips

On Wednesday January 18th Kofi Makinwa, chair of the Microelectronics Department has participated in the radio show of Business News Radio 'Ask Me Anything' presneted by Jörgen Raymann. The topic of the show is the influence on our daily lives of computer chips. Besides Professor Kofi Makinwa Professor Bram Nauta from the University of Twente participated as well. The public was given the opportunity to submit questions for the two professors. Listen to the show online Listen to the show online


Kofi's VLSIx webinar on Smart Sensor Design is now on-line!

Kofi's VLSIx webinar on Smart Sensor Design is now on-line! http://resourcecenter.sscs.ieee.org/sscs/product/vlsix/SSCSVLSI0031
Kofi's earlier ISSCC tutorials are also available on the SSCS site. Topics covered are:


Kofi visits the Indian Institute of Technology, Madras

Kofi, Shanthi (Pavan) and the attendees of his "Smart Sensor Design" class at the Indian Institute of Technology, Madras


Six talks at ISSCC 2017!

Lab members will be responsible for 6 talks at ISSCC 2017! Hui, Sining, Vikram and Bahman will be presenting regular papers (on bridge readout, resistor-based temperature sensors, eddy-current sensors and BJT-based temperature sensors, respectively), Fabio contributed to a paper about Cryo-CMOS, while Kofi has an invited talk on micropower ADCs.


Kofi and Said visit Cypress Semiconductor (Cork)

Kofi and Said visit Cypress Semiconductor (Cork)

From left to right, Dermot, Paul, Said and Kofi at the kick-off meeting of Said's MSc project (on the design of a nanopower capacitive sensor).


Vacancy: Team manager for Electrical Engineering Education (EEE)

The Faculty of EEMCS is creating a special team to fully focus on teaching using our unique and innovative ‘Delft method’. This method integrates practical and theoretical electrical engineering education and trains students to be hands-on, theoretically versed electrical engineers ready for a future career in science or industry.

We are looking for a team manager specialising in Electrical Engineering Education (EEE) who will be both a group leader and a teacher in his/her capacity as the role model of EE Education.

More information


Marcel Pelgrom receives Kirchhoff Award

The Electronic Instrumentation Laboratory congratulates Prof. Marcel Pelgrom with the prestigious Kirchhoff Award 2017. Prof. Pelgrom, who is guest lecturer for our course “Nyquist-Rate Data Converters”, receives this award “for seminal contributions to systematic analysis of random offsets in semiconductor devices and their impact on circuits.” The award will be officially presented to Marcel at the ISSCC in February 2017 in San Francisco.


Pelin has won Best Student Paper Award

Pelin has won Best Student Paper Award

More ...


7 July 2016: Opening of CryoLab for Extremely Sensitive Electronic Measurements

The CryoLab of TU Delft's Faculty of EEMCS has been opened on Thursday 7 July by the dean Rob Fastenau. TU Delft scientists from the Tera-Hertz Sensing Group, Jochem Baselmans and Akira Endo, will be leading a team of young scientists and engineers working in the lab on astronomical instrumentation. The first instrument, DESHIMA (Delft SRON High-redshift Mapper), is being developed to be operated on the ASTE telescope in the Atacama Desert in Chile. The goal of the research is to create 3D charts of so-called submillimetre galaxies that, in contrast to 2D charts, also show distance and time.

The large number of superconducting detectors, and the advanced electronics developed at SRON, allows DESHIMA to map a very large volume of space at once. While Endo leads the development of DESHIMA, Baselmans will soon install the next cryostat for testing novel THz array antennas, that will enable his upcoming instrument MOSAIC to target multiple galaxies at once. In the future, the CryoLab is envisioned to also host new coolers from QuTech. Superconducting electronics used for astronomical instrumentation and quantum electronics have much in common, because they both push the limits of what can be observed.


4 papers at VLSI

PhD candidates Bahman and Saleh presented a 60mK-accurate temperature sensor and a 36A integrated current sensing system, respectively, while Kristof (now at NXP) presented an energy-efficient SoC in which a microprocessor and its memory are stacked and so share the same supply current. Chao presented a front-end ASIC with receive sub-array beamforming integrated with a 32 × 32 PZT matrix transducer for 3-D transesophageal echocardiography.


A snowy visit to AACD 2016

A snowy visit to AACD 2016


3 papers at VLSI 2015!

PhD candidates Bahman and Saleh will be presenting a 60mK-accurate temperature sensor and a 36A integrated current sensing system, respectively, while Kristof (now at NXP) will be presenting an energy-efficient SoC in which a microprocessor and its memory are stacked and so share the same supply current.


Burak wins ICT.OPEN2016 and ProRISC best poster award

Burak wins the best poster award of both ICT.OPEN2016 and ProRISC track. The title of the poster is "An Energy Efficient Dynamic Zoom-ADC for Audio Applications".


Happy 2016!

Here are some pictures of the New Year Reception of the Microelectronics department

More ...


Bahman wins Analog Devices Outstanding Student Award

Bahman Yousefzadeh has won the 2015 Analog Devices Outstanding Student Award. The award consists of a travel grant that partially covers the costs of attending ISSCC.


Saleh wins IEEE SSCS Predoctoral Achievement Award!

Saleh Shalmany has won the prestigious IEEE Solid-State Circuits Society Predoctoral Achievement Award! Given to promising graduate students, the award mainly consists of a fully sponsored trip to ISSCC.


Caspar gets his PhD

Caspar gets his PhD


Wouter wins a best presentation award from IECON 2015

Wouter Brevet presented a paper about a smart wind sensor at IECON2015 in Yokohama, Japan. The paper, entitled "A 25mW Smart CMOS Wind Sensor with Corner Heaters," received a Best Presentation award.


Junfeng awarded an ASSCC travel grant

Junfeng Jiang was awarded a Student Travel Grant for ASSCC 2015. At the conference, he presented a paper entitled “A Multi-Path CMOS Hall Sensor with Integrated Ripple Reduction Loops.”


TU Delft Female Fellowship Tenure Track Openings

Academic openings at all professor levels

More ...


Seven talks at ISSCC 2016!

Lab members will be presenting 7 talks at ISSCC 2016! PhD candidates Junfeng, Ugur and Burak have regular papers (on wide-band magnetic sensors, tiny temperature sensors and energy-efficient ADCs), while Fabio, Kofi and Albert have invited talks (on frequency references, calibration techniques, temperature sensors and image sensors).


ISCAS 2015 Keynote Presentation Ronald Dekker online

Ronald Dekker's Keynote: From Chips for the Living to Living Chips

Micro-fabricated devices are finding their way to the frontend of medical equipment, where they are the interface between body, or in general living tissue, and machine. They enable better and cheaper diagnostic equipment, they add eyes and ears to minimally invasive instruments such as laparoscopic instruments and catheters, they allow for un-obtrusive monitoring of body functions, they add functionality to implants, and they enable the development of better and personalized medicines. Despite their great promise it has been proven difficult to bring these devices out of the laboratory phase into production. One of the reasons is the lack of a suitable fabrication infrastructure. Much more than standard CMOS or MEMS devices, these medical devices rely on the processing of novel materials, especially polymers, in combination with advanced molding, micro-fluidics, and assembly technologies. At the same time these devices have to be fabricated under strict quality control conditions in a certified production environment.

In the recently granted ECSEL project InForMed a supply chain for the pilot fabrication of these medical devices is organized, which brings together key European technology partners in an integrated infrastructure linking research to pilot and high volume production. The pilot line is hosted by Philips Innovation Services, and open to third party users.

Speaker Biography:

Ronald Dekker received his MSc in Electrical Engineering from the Technical University of Eindhoven and his PhD from the Technical University of Delft. He joined Philips Research in 1988 where he worked on the development of RF technologies for mobile communication. Since 2000 his focus shifted to the integration of complex electronic sensor functionality on the tip of the smallest minimal invasive instruments such as catheters and guide-wires. In 2007 he was appointed part time professor at the Technical University of Delft with a focus on Organ-on-Chip devices. He published in leading Journals and conferences and holds in excess of 50 patents.

More ...


Fabio Sebastiano is now an Assistant Professor!

Fabio Sebastiano is now an Assistant Professor!


Medical Delta speeds up development of cochlear implants

Uit De Audiciens, februari 2015: CIs (cochleaire implantaten, Red.) volop in ontwikkeling.

Het is een traditie, de refereeravond van KNO/Centrum voor Audiologie en Hoorimplantaten (CAHIL) in het LUMC op de tweede donderdag van het jaar.

Ook op 8 januari 2015 zit de collegezaal weer vol. Het is dan ook een bijeenkomst waar een aantal disciplines uit de hoorbranche samenkomen. KNO-artsen, audiologen, akoepedisten, audiciens, fabrikanten en anderen luisteren naar voordrachten die inzicht geven in nieuwe ontwikkelingen op audiologisch gebied.

De avond wordt geopend door prof. dr. ir. J.H.M. Frijns, hoofd CAHIL. () In het kader van de Medical Delta (een samenwerkingsverband tussen het Erasmus MC in Rotterdam, de TU Delft en het LUMC in Leiden voor de ontwikkeling van medische technologie) is er een presentatie van Johan de Vos die als arts-onderzoeker KNO onderzoek verricht naar nieuwe technologie voor cochleaire implantaten. Onder begeleiding van Wouter Serdijn en Paddy French hebben drie promovendi van de TU een meetversterker (Cees Jeroen Bes), een elektrode ontwerp (Nishant Lawant) en een stimulatorchip (Wannaya Ngamkham) ontwikkeld. Deze technologie wordt onder leiding van Johan Frijns en Jeroen Briaire in het LUMC geimplanteerd en getest door Johan de Vos. Tevens ontwikkelt het LUMC nieuwe meetmethodes voor het terugmeten van de respons van de gehoorzenuw (Dick Biesheuvel).

Lees meer hier: http://bioelectronics.tudelft.nl/~wout/documents/news/lumc_refereeravond_20150108.pdf

More ...


Burak wins ProRISC best poster award

Burak wins ProRISC best poster award.


Rui presents the world's smallest smart temperature sensor at ISSCC 2016.

Rui presents the world's smallest smart temperature sensor at ISSCC 2016. Watch here Rui's presentation.


Jiawei Xu wins the IEEE SSCS Predoctoral Achievement Award 2014-2015!

Jiawei Xu has won the prestigious IEEE Solid-State Circuits Society Predoctoral Achievement Award 2014-2015! Given to promising graduate students, the award essentially consists of a free trip to ISSCC 2015.


MP Jan Vos visits PARSAX

On Friday 7 November, Jan Vos, MP for the PvdA, visited the TU Delft Climate Institute. The theme of the visit was climate change, TU Delft's research and the usefulness of and need for climate monitoring. The programme included a demonstration of cloud simulations in the Virtual Lab and a visit to the PARSAX radar. Thanks to the rain, it was possible to obtain good live measurements.


Albert Theuwissen honored with European SEMI Award 2014

Albert Theuwissen, CEO of Harvest Imaging and professor at Delft University of Technology, is the recipient of the European SEMI Award 2014. The Award, which recognizes Theuwissens outstanding contribution to the continuing education of engineers, was presented during the SEMICON Europa Executive Summit in Grenoble today.

Albert Theuwissen is professor at the Electronics Instrumentation Laboratory of Delft University of Technology. He is a highly regarded specialist in solid-state image sensors and digital imaging. He worked for nearly 20 years at Philips Research and then at DALSA in lead engineering and management roles. In 2001, Theuwissen became a part-time professor at Delft University of Technology. In 1995, he wrote the textbook Solid-State Imaging with Charge-Coupled Devices which is now a standard reference work in the field of solid-state imaging.

After retiring in 2007, Theuwissen founded Harvest Imaging and has played a major role in the continuing education of engineers in the field of solid-state imaging and digital cameras. He has taught and trained over 3,000 engineers at image sensor companies (such as Kodak, Sony, Samsung, Aptina, ST Microelectronics, Micron, Intel, Philips, Canon, DALSA, and Panasonic) and consumer product companies (such as Nokia, Sony-Ericsson, Motorola, Siemens, Research InMotion, Thomson, and many others). In addition, he has conducted short courses at IEEEs IEDM, ISSCC, ICIP and SPIEs Electronic Imaging Conference.

Solid-state image sensors such as the Charge-Coupled Device (CCD) and CMOS Image Sensor (CIS) are complex electron devices. About one billion image sensor chips are fabricated and sold each year and represent a multi-billion dollar per year IC business segment. Understanding the fabrication and device physics operation of these devices is difficult and is rarely taught in universities at either the undergraduate or graduate level.

Solid-state image sensors such as the Charge-Coupled Device (CCD) and CMOS Image Sensor (CIS) are complex electron devices. About one billion image sensor chips are fabricated and sold each year and represent a multi-billion dollar per year IC business segment. Understanding the fabrication and device physics operation of these devices is difficult and is rarely taught in universities at either the undergraduate or graduate level.

Albert recognized the need for technical education and created a successful continuing education offering that navigates and conforms to the competitive and proprietary IP environment, benefitting thousands of electron-device engineers and also the industry, said Heinz Kundert, president of SEMI Europe. It is an honor to recognize Albert for his outstanding contributions to the European semiconductor and microsystems industry.

The European SEMI Award was established more than two decades ago to recognize individuals and teams who made a significant contribution to the European semiconductor and related industries. Prior award recipients hailed from these companies: Infineon, Semilab, Deutsche Solar, STMicroelectronics, IMEC, Fraunhofer Institute, and more.


Ugur at the STW congress demonstrating his TD sensors

During the STW annual congress, Ugur Sonmez demonstrated the world's smallest TD sensor (8000um2) to attendees. Details about the sensor were presented at ESSCIRC 2015.


ISCAS 2014 a big success!

Wouter Serdijn (Section Bioelectronics) served as Technical Program Chair for this year's edition of ISCAS. Next year's edition will be held in Lisbon, Portugal. For this edition Wouter Serdijn will change hats and be General Chair.


Ugur wins Analog Devices Outstanding Student Award

Ugur Sonmez has won the 2013 Analog Devices Outstanding Student Award. The award consists of a travel grant that partially covers the costs of attending ISSCC.


Qinwen gets her PhD

Qinwen gets her PhD


Muhammed gets his PhD

Muhammed gets his PhD


Muhammed wins JSSC Best Paper Award

Muhammed Bolatkale, Robert Rutten, Lucien Breems and Kofi Makinwa have won the 2011 Journal of Solid-State Circuits (JSSC) best paper award for a paper describing a high-speed continuous-time delta-sigma ADC with a record-breaking bandwidth of 125MHz. The JSSC is the world's foremost journal in the area of integrated circuit design.


Kofi recognized as an ISSCC Top Ten Author

At the 60th anniversary of the International Solid-State Circuits Conference (ISSCC), Kofi Makinwa was recognized as one of its top ten contributing authors. The ISSCC is the flagship conference of the IEEE Solid-State Circuits Society.


Kamran wins SSCS Predoctoral Award

Kamran Souri has won the The IEEE Solid-State Circuits Society Predoctoral Achievement Award 2012-2013! Given to promising graduate students, the award essentially consists of a free trip to ISSCC 2013.


TU Delft wins Gold at the Chip Olympics

With 12 regular papers and 1 invited talk, the TU Delft is the top contributor to this year's International Solid-State Circuits conference - popularly known as the chip Olympics. The Precision Analog Group contributed four of these papers.


Muhammed wins ISSCC Best European Paper Award

Muhammed Bolatkale, Robert Rutten, Lucien Breems and Kofi Makinwa have won the ISSCC 2011 Jan van Vessem Award for Outstanding European Paper for their work on a high-speed continuous-time delta-sigma ADC in a 45nm CMOS process. The ADC has a bandwidth of 125MHz and operates at a 4GHz sampling frequency. The ISSCC is the world's leading conference on the design of integrated circuits.


Kofi's group in 2012


Youngcheol gets a VENI grant

Youngcheol Chae has been awarded a VENI grant by NWO. The Veni grant is awarded to excellent post-doctoral researchers to allow them to develop their ideas for a further three years.


Caspar wins Transducers Best Paper Award

Caspar van Vroonhoven and Kofi Makinwa have won a best paper at Transducers 2011 for their work on a temperature sensor based on the well-defined thermal diffusivity of silicon. The sensor achieves an inaccuracy of ±0.6°C over a wide-range (-70°C TO 170°C). Transducers is the world's largest conference on microsensors, microactuators and microsystems.


Caspar demos at ISSCC 2011

At ISSCC 2011, Caspar van Vroonhoven demonstrated a 250°C-capable temperature sensor based on the relative thermal diffusivities of silicon and silicon dioxide.


Kofi becomes an ISSCC Fellow

Kofi Makinwa has become a fellow of the IEEE "for the development of precision analog circuits and integrated sensor systems. IEEE Fellow is one of the most prestigious honors of the IEEE, and is bestowed upon a very limited number of Senior Members who have made outstanding contributions to the electrical and information technologies and sciences"


Mahdi wins ESSCIRC Young Scientist Award

Mahdi Kashmiri and Kofi Makinwa have won the Young Scientist Award of the 35th European Solid-State Circuits Conference (ESSCIRC 2009) for their work on a digitally-assisted electrothermal frequency-locked loop. This is the first fully integrated implementation of such a loop, which locks the output frequency of an on-chip oscillator to the thermal diffusivity, i.e. the rate of heat diffusion, of bulk silicon. Since bulk silicon is very pure, the spread of the loop's output frequency is less than 1000ppm after a single room-temperature trim.


Kofi gives his inaugural lecture

Kofi Makinwa gave his inaugural lecture: Sensing the future. This lecture can be seen here


Seven for ISSCC

Seven for ISSCC! Research carried out under the supervision of Prof. Kofi Makinwa and in collaboration with NXP and the University of Twente, has led to seven papers at the prestigious International Solid-State Circuits Conference (ISSCC). The papers describe advances in temperature sensors, frequency references, voltage references, precision amplifiers and ultra-low-power radios.


Kofi appointed Antoni van Leeuwenhoek Professor

TU Delft has appointed Dr. Kofi Makinwa to the post of Antoni van Leeuwenhoek Professor. TU Delft's Antoni van Leeuwenhoek chairs are aimed at promoting young, excellent scientists to professorships at an early age so that they can develop their scientific careers to the full.


Caspar wins ISSCC Best European Paper Award

Caspar van Vroonhoven and Kofi Makinwa have won the ISSCC Jan van Vessem Award for Outstanding European Paper for their work on a new smart sensor which measures the temperature of microchips precisely on the basis of heat diffusion in silicon. The sensor provides a solution for heat management in microprocessors, a function which has become increasingly important thanks to the miniaturisation of the past few years. They previously won an IEEE Sensors 2008 Best Student Paper Award for a similar sensor. The ISSCC is the world's leading conference on the design of integrated circuits.

Agenda

Bioelectronics Colloquium

On the Relationship between Nyquist Rate and Healthcare: Silicon Systems to Close the Sub-Sampling Gap in Health Screening and Monitoring

Amin Arbabian, PhD (Stanford University)

Abstract
Advances in healthcare technologies have mainly focused on therapeutics, interventional procedures, and “late-stage” diagnostics. These steps have undergone significant improvements, leading to higher survival rates and enhancements in quality of life. Nevertheless, current trends are unsustainable due to the inadequate outcomes on specific critical diseases and skyrocketing national healthcare costs. An important example is cancer, where mortality rates have not seen major improvements, even with the tremendous technological advances in diagnostic imaging tools over the last four decades.

In this talk I will outline our efforts in better marrying technology and healthcare with new systems that 1) enable continuous “Nyquist” imaging and screening to enable preventive/predictive care, and 2) introduce smart implants for precision monitoring and closed-loop therapies. Preventive screening through continuous monitoring has the potential to fundamentally revamp our understanding of disease as well as targeted therapy. Today, the human body is monitored infrequently, perhaps on an annual basis and with a low “resolution”. This is in contrast with advanced electronic systems (many of which our community designs and ships), which are frequently monitored and calibrated. I will summarize a few example projects that aim to address these issues, including portable, semiconductor-based, “Tricorder” imaging systems, ultrasound-powered implantable devices that can measure, detect, and act upon local physiological changes through closed-loop neuromodulation or “electroceuticals”, and finally our new investigation of a noninvasive methods of neuromodulation based on ultrasonic excitation.

Biography
Amin Arbabian received his Ph.D. degree in EECS from UC Berkeley in 2011 and in 2012 joined Stanford University, as an Assistant Professor of Electrical Engineering. His research interests are in mm-wave and high-frequency circuits and systems, imaging technologies, and ultra-low power sensors and implantable devices. Prof. Arbabian currently serves on the steering committee of RFIC, the technical program committees of RFIC and ESSCIRC, and as associate editor of the IEEE Solid-State Circuits Letters (SSC-L) and the IEEE Journal of Electromagnetics, RF and Microwaves in Medicine and Biology (J-ERM). He is the recipient or co-recipient of the 2016 Stanford University Tau Beta Pi Award for Excellence in Undergraduate Teaching, 2015 NSF CAREER award, 2014 DARPA Young Faculty Award (YFA) including the Director’s Fellowship in 2016, 2013 Hellman faculty scholarship, and best paper awards from several conferences including ISSCC (2010), VLSI Circuits (2014), RFIC symposium (2008 and 2011), ICUWB (2013), PIERS (2015), and the MTT-S BioWireless symposium (2016).

Additional information ...


Chip Design Workshop

IEEE Solid-State Circuits Society

Program: 12:30 Coffee, 12:50 Welcome, Kofi Makinwa, TU Delft, 13:00 Introduction, Patrick Reyanert, KU Leuven, 13:15 – 13:40 A Dynamic Zoom ADC with 109 dB DR for Audio Applications, Burak Gönen, TU Delft, 13:40 – 14:00 A 0.3-2.6 TOPS/W Precision-Scalable Processor for Real-Time Large-Scale ConvNets - Bert Moons, KU Leuven, 14:20 – 14:45 Coffee Break, Talks by Benelux Chip Design Contest Winners: 14:0 – 14:20 A 94.6%-Efficiency Fully Integrated Switched-Capacitor DC-DC Converter in 40nm - Nicholas Butse, KU Leuven, Talks by Invited Speakers: 14:45 – 15:15 Design mistakes you’d rather not talk about, Klaas Bult 15:15 – 15:45 Cryo-CMOS for Quantum Computing, Fabio Sebastiano, TU Delft,


Seminar autonomous driving

Autonomous driving

Leo de Vreede, Alexander Yarovoy, Cicero Vaucher, Riender Happee, Dariu Gravila, Rossiza Gourova, Joris Domhof

Program 11.00 - 11.05 Opening (by Alexander Yarovoy and Leo de Vreede 11.05 - 11.35 S4-Drive project (PhD’s Rossiza Gourova (EEMCS) and Joris Domhof (3ME)) 11.35 - 12.05 Dariu Gavrila,‘Autonomous driving' 12.05 – 13.35 Riender Happee,‘Human Factor on autonomous driving’ Lunch break Lipkenszaal 13.00 - 13.30 Cicero Vaucher,‘Automotive radars’ 13.30 -14.00 CRUISE project proposal (Cicero Vaucher, Masoud Babaie and Faruk Uysal)


Conferences

Eurosensors dead-line


Professoren in de Arena

Professoren in de Arena: De bionische mens, van protheses naar upgrades

Wouter Serdijn, Just Herder, Harrie Weinans, Project March

Op 28 maart gaan drie hoogleraren, waaronder Wouter Serdijn, met elkaar in debat over 'de bionische mens'. Wat is er mogelijk en hoe ver kun, wil en mag je gaan? In drie korte minicolleges praten de heren u bij en worden ze vervolgens stevig aan de tand gevoeld door cabaretier, columnist en TU-docent Jasper van Kuijk. In de discussie die daarop volgt, wordt het publiek van harte uitgenodigd mee te doen.

De sprekers van deze avond zijn:

Just Herder - Professor of Interactive Mechanisms and Mechatronics

Harrie Weinans - Professor of Tissue Biomechanics and Implants

Wouter Serdijn - Professor in Bio-Electronics

Project March

Deze editie van ‘Professoren in de Theaterarena’ wordt georganiseerd i.s.m. het ‘Explore your Brain’ evenement van de TU Delft Library in het kader van het 175 jarig bestaan van de TU Delft.

Over Professoren in de Arena

In nauwe samenwerking met de TU Delft en de universiteiten van Leiden en Rotterdam zetten wij in een theatrale setting steeds drie spraakmakende hoogleraren op het podium rondom een actueel thema. Deze onderwerpen worden van verschillende kanten belicht, vanuit de harde wetenschap en/of maatschappelijke en ethische hoek. In een magazine-achtig format met korte colleges, stand-up colums wordt u bijgepraat en doet u mee in de discussie.

Locatie: Theatercafé, Theater de Veste

Additional information ...


Microelectronics Colloquium

Microelectronics Department Colloquium

Daniele Cavallo, Vasiliki Giagka, Fabio Sebastiano, Rob Remis

On Wednesday March 15 the next Microelectronics colloquium wil take place, including four lectures by staff members.

Please register online by completing the form.

  • Vasso Giagka
    Flexible bioelectronic medicines

    Abstract: Bioelectronic medicines are the next generation of neuromodulation devices: small active three-dimensional neural interfaces able to modulate nerve activity by targeting a specific neural region. They aim to treat a number of conditions, such as diabetes and asthma, in a tailored (per individual) and reversible fashion, avoiding the side effects of conventional drug-based interventions (pharmaceuticals). They achieve so by recording signals from the respective nerves, extracting information and using it as feedback to electrically stimulate the neural region in a closed-loop manner.

    Current technologies for active implants have not yet managed to achieve the miniaturisation and integration levels required for the development of bioelectronic medicines. For such breakthrough devices, novel concepts need to be explored, developed, and tested.

    In this talk I will present my current activities as well as my vision on realizing the first flexible three-dimensional graphene active implant, for safe chronic neural stimulation and recording from the peripheral nerves.

  • Fabio Sebastiano
    Cryo-CMOS for Quantum Computing: does it work?

    Quantum computing holds the promise to change our lives by efficiently solving computing problems that are intractable today, such as simulation of quantum systems for synthesis of materials and drugs. A quantum computer comprises both a quantum processor and a classical electronic controller to operate and read out the quantum devices. The quantum processor must be cooled at cryogenic temperature in order to show quantum behavior, thus making it unfeasible to wire thousands of signals from the cryogenic quantum devices to a room-temperature controller.

    While this issue can be solved by placing also the electronic controller at cryogen¬ic temperature, which electronic technology is the best choice for its implementation? This talk will address the challenges of building such electronic controller, and answer whether a standard CMOS technology can be employed for the required analog and digital circuits operating at 4 K and below.

  • Daniele Cavallo
    Advanced Antenna Arrays for Modern Radar and Communication Systems

    Abstract: Several of today’s radar and wireless communication applications are shifting their operation to higher frequency to fulfil more demanding requirements on resolution, compactness and data rates. For this reason, there is a growing need to develop low-cost integrated circuit transceivers working at millimeter and sub-millimeter waves.

    However, on-chip antennas are currently characterized by very poor radiation efficiency and extremely narrow bandwidth. My approach of combining the concepts of connected arrays with artificial dielectrics will solve the inefficiency problem and enable high-efficiency on-chip antenna designs.

    Similar concepts can be also realized at microwave frequencies in printed circuit board, allowing for low-cost phased array antennas with state-of-the-art performance in terms of scan range, bandwidth and polarization purity.

  • Rob Remis
    Imaging with Waves

    We present an overview of our current wave field imaging and inversion research. Effective inversion strategies for important applications in Magnetic Resonance Imaging (MRI), nano-optics, and subsurface monitoring will be discussed. In particular, dielectric shimming (shaping of the radio frequency field in MRI) as well as inversion algorithms that determine the dielectric properties of various tissue types based on measured MRI data will be considered, and state-of-the-art model-order reduction techniques for large-scale wave propagation problems will be discussed as well.


MS3 seminar

Capabilities and Research Activities at the University of Oklahoma Advanced Radar Research Center

Prof. Nathan A. Goodman
The Advanced Radar Research Center (ARRC) at the University of Oklahoma

The Advanced Radar Research Center (ARRC) at the University of Oklahoma consists of a vibrant group of faculty and students from both engineering and meteorology, focused on solving challenging radar problems and preparing the next generation of students. Through the collaborative nature instilled in its members, the ARRC has proven effective at developing synergy between science and engineering in the field of radar. The ARRC resides in state-of-art Radar Innovations Laboratory, a one-of-a-kind and unrivalled facility for radar research, development, and education. This 35,000-sqft facility includes microwave labs, advanced fabrication capability, and two anechoic chambers.

Bio Prof. Goodman: Nathan A. Goodman received the B.S., M.S., and Ph.D. degrees in electrical engineering from the University of Kansas, Lawrence, in 1995, 1997, and 2002, respectively. From 1996 to 1998, he was an RF systems engineer for Texas Instruments, Dallas, TX., and from 2002 to 2011, he was a faculty member in the ECE Department of the University of Arizona, Tucson. He is now a Professor in the School of Electrical and Computer Engineering and Director of Research for the Advanced Radar Research Center at the University of Oklahoma, Norman.


MS3 seminar

MS3 Master Event

Come to learn about our group and current Master Thesis Projects...

Additional information ...


Microelectronics Introduction Colloquium

Introduction 3 new Tenure Trackers

Masoud Babaie, Morteza Alavi, Faruk Uysal

On December 12 we organize the next Microelectronics Colloquium to introduce three new Assistant Professors (Tenure Trackers) of the Microelectronics department. They are happy to present a lecture about their research.

The colloquium start at 15.00 hrs. there will be a drink afterwards in the foyer.
Location: Theatre of Culture Builing (38) Mekelweg 10.
Please register online if you want to attend, latest December 5.

  • Masoud Babaie: Pushing The Limits of CMOS Circuits for Emerging Technologies
    Within the next few years, quantum processors, Fifth Generation (5G) cellular systems and the wireless Internet-of-Things (IoT) are expected to see significant deployment to realize more integration between the physical and digital worlds, promising enormous computation power, high data rate communications and enabling more objects to be remotely sensed and controlled.

    This talk will address some of the main challenges in the design and implementation of IoT devices, mm-wave 5G transceivers, and cryogenic CMOS controller for quantum computers. An overview of my past and ongoing research activities will be also presented, with emphasis on novel solutions to improve power efficiency and spectral purity of RF/mm-wave transceivers.

  • Morteza Alavi: Universal Transmitters for 5G
    Today, our daily activities are intertwined with the Internet. The ever-growing demand to swiftly get access to the data-cloud systems leads to huge data traffic. In order to seamlessly transmit and receive these gigantic data, _ 40 GB, agile radio-frequency (RF) transceivers are inevitable.

    These radios must be capable of supporting the current and future communication standards such as 5th generation of wireless mobile communications. The ultimate goal is that they can be implemented as universal radios whose modes of operation can be defined by their clients. To address these demands, RF transmitters are currently reinvented and are directed towards digital-intensive architecture. In this short presentation, we will briefly describe the strengths,possibilities, and challenges that exist for these advanced transmitters. First and foremost, the concept of RF-DAC based transmitters will be introduced. Next, the talk will review various RF-DAC based transmitters that have already been implemented at ELCA. Eventually, the presentation will concisely unveil the future directions of the research of these software-defined transmitters at ELCA.

  • Faruk Uysal: Distributed Radar Networks: Beyond a single radar
    The number of operational radar is rapidly increasing due to the growing demand of the remote sensing. Software defined radio and emerging single-chip radar technology make use of radars in every aspect of life such as autonomous driving, safety and security applications. With the increase of active transmitters, spectrum management and coexistence started to become a concern for some radar systems. In this talk, the previous applications of waveform, frequency agility will be reviewed to bring multi-functionality to the modern radar system. Finally, we will discuss the future research for distributed radar networks and how to fuse data from various radars to acquire different aspects of a target to be viewed simultaneously.


MSc BME Thesis Presentation

Wireless Power Transfer and Optogenetic Stimulation of Freely Moving Rodents

Farnaz Nassiri Nia

Animal studies are commonly used to test the feasibility and effectiveness of promising novel neuroscience research ideas. One such new technique is optogenetic stimulation, which refers to stimulation of the brain by means of light. Current optogenetic stimulation methods use tethered setups and, typically, the animal-under-study is put into a fixed position. This introduces stress, an obvious reduction in animal welfare, and may thus influence the experimental results. Hence, an untethered setup is highly desirable. Therefore, in this thesis, we propose a complete wireless optogenetic stimulation setup, which allows for full freedom of movement for multiple rodents-under-study in a 40x40x20 cm environment.

This thesis includes a thorough design space exploration and the subsequent development of: an inductive wireless link, a wireless receiver module that resides on the animal, and novel micro-LED array implants.


MSc ME Thesis Presentation

A 0.6V Low Noise Current Generator for Bio-Impedance Measurements in 40nm CMOS

Yao Li


PhD Thesis Defence

Energy-Efficient Smart Temperature Sensors in CMOS Technology

Kamran Souri

Additional information ...


MSc ME Thesis Presentation

Structured electronic design of high-pass ΣΔ converters and its application to cardiac signal acquisition

Samprajani Rout

Abstract:

With the bandwidth of the ECG signal extending from sub-Hz to 200 Hz, a major challenge in developing the analog front-end responsible for digitizing the analog signal for an ECG readout system lies in implementing the large time-constants on chip due to area constraints. While techniques to obtain very large time constants exist, they are heavily limited by both linearity and accuracy, which clearly dictates the need for alternative structures.

In this thesis, a ΣΔ converter is used for its noise-shaping property to digitize the acquired signal. A structured electronic design methodology based on state-space forms is proposed to develop high-pass (HP) ΣΔ converter topologies. As opposed to conventional low-pass or band-pass ΣΔ, a generalized signal transfer function which includes the high-pass characteristic is used. The proposed HP ΣΔ topologies satisfy the signal transfer function, which is high-pass characteristic in this application and the noise transfer function, which is a 2-nd order noise shaping in this case. Furthermore, the noise contribution of each of the integrators is evaluated and the topologies are compared in terms of their total noise contribution. Finally, one of the structures is implemented in 0.18 um technology as a final step of verification.

Additional information ...


MSc BME Thesis Presentation

aEEG analog front-end IC for neonatal brain development monitoring

Maciej Kostalkowski

Abstract:

Every year number of prematurely born infants grows. Most underdeveloped organ after birth is brain. Therefore its monitoring is very important, especially as it can provide indications about health state in a future, both short and long term. Non invasive method of brain monitoring is aEEG recording.

Although aEEG is already well known and accepted in neonatology, it is still not used to monitor every patient. Problem is high price of a device starting from 30000 euro. In a result, hospital is not able to provide proper monitoring for each and every patient. For this reason, main task of this thesis is to propose cheaper version of a system.

In order to propose cheap design, minimal requirements have to be specified. Two tests were performed. First one was to identify interferences disturbing aEEG recording. Only registered interference was 50Hz spike coming from the mains. Noise floor peak to peak amplitude was measured on 1μV level, while magnitude of 50Hz spike was on the level of 9μV for devices turned off and 25μV for devices turned on.
Second performed test was resolution test. Test showed that in order to keep the number of bits low, amplification of the signal is required. Amplification by factor of 1000 allowed to reduced this value to 7bits.

Proposed system consists of amplifying stage realising 60dB gain with high pass cut off filtration and ADC. Amplifying stage is realised by amplifier providing 35dB gain with filtration below 2Hz and second amplifier realising 25dB gain. ADC is implemented by continuous time second order Sigma Delta Modulator. Proposed system was designed in CMOS 0.18μ and h18a6am technology. Tests of full system showed SNR no lower than 51dB, power consumption of 217.5μV. Input stage has CMRR of 113dB and input impedance above 2.25GΩ for the bandwidth 2-15Hz. System reliability was checked with corner analysis and wide range of temperatures. Results showed small variations of SNR.


MSc ME Thesis Presentation

A 0.6V, 1uW, 0.95µVrms low-power low-noise instrumentation amplifier for ECG/BioZ in 40nm CMOS

Qiuyang Lin

Abstract:

This thesis presents a low-power low-noise instrumentation amplifier designed to be implemented in 40 nm CMOS technology and operating from a 0.6 V supply, intended for use in electrocardiogram (ECG) and bio-impedance (BioZ) signal acquisition. This instrumentation amplifier has one ECG channel, one BioZ channel and allows both signals to be measured at the same time.

The core of the system is an AC-coupled instrumentation amplifier. A DC servo-loop is applied to handle large differential electrode offset (>300 mV) and a positive feedback loop is used to boost the input impedance (>100 MOhms). This instrumentation amplifier achieves low noise (<1 uVrms over a bandwidth of 150 Hz), large CMRR (>100 dB) while only consuming 1 uW of power. The instrumentation amplifier has a noise efficiency factor (NEF) of 2.4 and it occupies only 0.1 mm^2 chip area.

Additional information ...


EI Colloquium

test

test


Special Celebrative Seminar: New model of Sino-Dutch R&D cooperation


Since the establishment of TU Delft's Beijing Research Centre (BRC) in 2012, 10 PhD researchers have been enrolled for this unique program in close cooperation with our Chinese Academic Partners. We are very pleased that the first two BRC PhD candidates will have their PhD thesis defence on September 19 2016, in the Aula of Delft University of Technology.

To celebrate this important milestone, we would like to invite you to join a special seminar after the defences, about the New model of Sino-Dutch R&D cooperation, to share the experiences, look to the future and raise the glass together.

Additional information ...


MSc ME Thesis Presentation

In-vivo multicell inferior olivary recordings: alternative design methods for creating cheap and flexible electrode structures

Joost Kerpels

In order to allow neuroscientists to do in-vivo recordings on hard to reach brain tissue, such as the Inferior Olivary Complex, specially designed electrodes are required. Although a variety of electrodes are commercially available, they are usually expensive and it is hard to rapid prototype new designs.

This thesis describes the design process of three electrode array designs, each improved based on the findings of the previous one. The first design was made using a FlexPCB production technique, on which gold spots were added to create conducting measuring sites. The second design combined this technique with commercial microwire electrodes. The third design used 3d-print technology combined with microwire electrodes to create an electrode array.

All designs were tested in in vivo measurements on mice. Although successful measurements were done, the robustness and reproducibility needs to improve in order for this technique to really be applicable in a laboratory environment. Furthermore, the peripherals need to be improved in order to minimize the system to create a wearable system and perform recordings on wake animals.

Additional information ...


MSc ME Thesis Presentation

A compact multi-electrode system to measure in vivo electrical activity in the olivocerebellar system -- measuring sub-threshold oscillations and action potentials spatially and over time

Matthijs Weskin

Additional information ...


MSc ME Thesis Presentation

Sensor Selection and Bit Allocation in WSNs with Realistic Digital Communication Channels

Hongrun Zhang

For energy management in wireless sensor networks, only the sensors with most informative measurements are activated to operate. How to select sensors that make good tradeoff between performance and energy consumption is what many researchers are focusing on. Existing solutions assume analog data model, i.e., the data from sensors collected by a center node, called fusion center, are analog measurements. In practical application, due to limitations of energy of sensors and bandwidth of wireless channel, original measurements are usually compressed before being transmitted to the fusion center. In addition, transmitted signals are usually distorted by wireless channel effects, therefore it is possible that the received data are corrupted with errors. In this thesis, we consider two compressive techniques: one-bit quantization and multi-bit quantization. In one-bit quantization, an indicator message is generated in a sensor according to whether the original measurement is larger than a threshold or not. In multi-bit quantization, the original measurements are quantized to multiple bits and only the most significant bits are reserved. The indicators or the most significant bits are then transmitted through realistic wireless channel to the fusion center for it to process. By these ways, the transmitted signals are digital, and they may flip into opposite values by the effects of wireless channels. For one-bit quantization case, we develop a sensor selection approach, based on convex programming. For multi-bit quantization, we extend the sensor selection to bit allocation and propose a novel algorithm to determine the number of bits to transmit for each sensors, which is also based on convex programming. In both cases we consider the effects of wireless channels, which are characterized as bit error rate. Particularly, for the multi-bit quantization, numerical results show that the bit allocation can further reduce the cost that we defined compared with existing solutions where transmitted data are assumed to be analog.


MSc ME Thesis Presentation

Low power digital baseband architecture for wireless sensor nodes

Yuteng Hao

This thesis presents a digital baseband design for an upcoming wireless standards: IEEE 802.11ah. It is a branch of Wi-Fi (IEEE 802.11) standards. Compared with the previous Wi-Fi standards, this new standard has larger coverage range and consumes less energy. It is particularly suited for energy-constrained sensor applications. In contrast to the Digital Baseband (DBB)s of other Wi-Fi standards, this design consumes much less power. The basic modulation method of the system is Orthogonal Frequency Division Multiplexing (OFDM) and the detailed algorithms are explored. To prove the robustness of the system, some error tests for the system are performed. A gate-level hardware design and the synthesis netlist are also presented to prove the low-power design. Based on the synthesis results, a series of optimization is done to lower the power consumption. The DBB has been implemented in 40nm Low-power CMOS process to prove the concept. It includes the key blocks of this system. Measurement results show that the DBB for IEEE 802.11ah is suitable for low power applications. The power consumption of this DBB is around 200 - 400 uW, which is hundreds times less than that of the traditional 802.11 baseband.

Thesis work performed at Holst Centre

Additional information ...


PhD thesis defence

Design of efficient and safe neural stimulators - a multidisciplinary approach

Marijn van Dongen

Neural stimulation is an established treatment methodology for an increasing number of diseases. Electrical Stimulation injects a stimulation signal through electrodes that are implanted in the target area of the central or peripheral nervous system in order to evoke a specific neuronal response that suppresses or treats pathological activity. This thesis discusses the design of neural stimulators: the device that is responsible for generating the stimulation signal in a safe, efficient and controlled manner. The design of such a device requires a highly multidisciplinary approach which involves disciplines such as neuroscience, electrophysiology, electrochemistry and electrical engineering.
The first part of this thesis focuses on the processes associated with the neuronal recruitment. After describing the stimulation processes in detail at various levels, the discussion zooms in on the processes at the electrode-tissue interface and in particular the electrochemical behavior. Many neural stimulators include coupling capacitors between the stimulator and the electrodes to reduce the risk of potentially harmful electrochemical reactions. However, it is shown that coupling capacitors also have negative implications that need to be considered, such as a shift in the equilibrium potential of the electrode-tissue interface. Also, the reversibility of charge transfer processes at the electrode-tissue interface is analyzed. Most studies rely on monitoring the electrodetissue interface potential to determine the maximum reversible charge injection limits. By measuring the reversible charge in a more direct way, it was found that irreversible charge transfer processes already play a role for stimulation intensities that are well below the established charge injection limits.
The extensive description of the stimulation process is furthermore used to introduce a fundamentally different stimulation paradigm. Instead of using a constant current or voltage to stimulate the electrodes, a high frequency, switched-mode stimulation signal is applied. The advantage of such a stimulation pattern is that it can be generated in a power efficient way by the neurostimulator circuit using switched-mode operation that is common in energy efficient amplifiers (class-D operation) or power management circuits. The efficacy of the proposed stimulation pattern is verified both using modeling as well as using in vitro measurements by analyzing the response of patch-clamped Purkinje cells.
The second part of the thesis focuses on the electrical design of neural stimulators. The first system is designed to be used in a specific neuroscientific experiment and features arbitrary waveform stimulation. The user has full flexibility over the choice of stimulation waveform, while the stimulator circuit guarantees safety by ensuring charge balanced operation. The stimulator circuit is realized and included in a system implementation that is suitable for the in vivo experimental setup. The stimulation pulse (which uses a burst pattern) is synchronized with auditory stimulation in an attempt to recondition the neural pathways in a mouse that suffers from tinnitus.
The second design implements the high-frequency switched-mode stimulation pattern that was introduced in the first part of the thesis. The system features an unfiltered forward buck-boost converter at its core to directly stimulate the target tissue. It is possible to operate the system with multiple independent channels that connect to an arbitrary electrode configuration, making the system well suited for current steering techniques. Furthermore, comprehensive control was implemented using a dual clock configuration that allows both autonomic tonic stimulation, as well as single shot stimulation. Each channel can be configured individually with tailored stimulation parameters and multiple channels can operate in a synchronized fashion. The system is power efficient, especially when compared with state-of-the-art constant current stimulators with an adaptive power supply that operate in multichannel mode. Efficiency improvements up to 200% compared with state of the art constant current stimulators are demonstrated. Furthermore, the number of external components required is reduced to a single inductor.

Additional information ...


Sense of Contact

Sensing and Stimulating the Body with Electroceuticals

Wouter Serdijn

The 21st century will be the century of unravelling the intricacies of the brain and in which we will explore the use of electricy to interact with our electro-chemical mainframe better. In this talk I will explain how electroceuticals, the electronic counterparts of pharmaceuticals, can help to successfully treat neurological disorders. Further, I will sketch a technological avenue of their future development by making electroceuticals smaller, more energy efficient and more intelligent.

Additional information ...


QuTech Seminar

Designs for quantum information hybrid devices and systems

Prof. Kae Nemoto
National Institute of Informatics, Quantum Information Sciences, Tokyo, Japan

There have been many architectures for quantum computer and quantum information devices proposed, yet we face a gap between these proof-of-principle idea and feasible quantum devices. We focus on an integrated cavity device based on a single diamond NV center to identify the problems and obstacles by integrating necessary elements to perform computational tasks.

Additional information ...


MEST event

TU Delft in ISSCC 2015

Program:

9:00 Prof. Kofi Makinwa Welcome
9:10 A. Carimatto A 67,392 SPAD PVTB-Compensated Multi-Channel Digital SiPMwith 432 column-Parallel 48ps 17b TDCs for Endoscopic Time-of-Flight PET
9:50 M. Shahmohammadi A 1/f Noise Up-conversion Reduction Technique Applied to Class-D and Class-F Oscillators
10:15 R. Quan A 4600um2 1.5oC (3s) 0.9kS/s Thermal-Diffusivity Temperature Sensor with VCO-Based Readout
10:40 Break
10:55 L. Xu A 110dB SNR ADC with +/-30V Input Common-Mode Range and 8uV offset for Current Sensing Applications
11:35 Y. He A 0.05-mm2 1-V Capacitance-to-Digital Converter Based on Period Modulation
12:00 H.Jiang A 30-ppm <80-nJ Ring-Down-Based Readout Circuit for Resonant Sensors

There will be free pizza from 12:45 to 13:15


Dimes Colloquium

Linear and nonlinear springs in electrostatic micro-actuators

David Elata
Technion - Israel Institute of Technology

In this presentation I will discuss the static and dynamic responses of mechanical springs that are used in electrostatic actuators. With respect to quasi-static applications, I will show how nonlinear mechanical springs can be used to counteract the nonlinear electrostatic attraction forces in gap-closing actuators. Instead of the pull-in instability, we may achieve an extended stable range with a linear voltage-displacement relation. Alternatively, beyond what would have been the pull-in point, we may achieve a constant voltage for any displacement. This effectively turns the transducer into a rechargeable mechanical battery, which is a neat design though mostly impractical. With respect to dynamic applications, I will show why the standard folded beam suspension, which is supposed to be linear by design, induces a nonlinear response in electrostatic comb-drive resonators. I will present a new suspension design which solves this problem.


International Radar Conference 2014, Lille, France

Alexander Yarovoy, François Le Chevalier, Fotios Katsilieris, Nikita Petrov, Alexey Narykov, Oleg Krasnov

The French SEE Society (Socit de l'Electricit, de l'Electronique, et des Technologies de l'Information et de la Communication) organises RADAR 2014 in Lille, from 13 to 17 of October 2014. The conference will be organized in the frame of the international relations set up between the Institution of Engineering and Technology (IET), the Institute of Electrical and Electronics Engineers (IEEE), the Chinese Institute of Electronics (CIE), the Institution of Engineers Australia (IEAust) and the SEE.

Additional information ...


MSc thesis presentation Thanos Ramkaj

Analysis and Design of High-Speed Successive Approximation Register ADCs

Thanos Ramkaj

HIGH performance Analog-to-DigitalConverters (ADCs) are highly demanded by modern instrumentation, data acquisition and wire-line/wireless communication systems. However, the need for high speed is always accompanied by high power consumption and large area since amplifiers with large bandwidth and analog devices with low noise and high linearity are mandatory to fulfill the stringent requirements of high speed operation. Benefits of technology scaling and the flexibility of digital circuits raise the design challenges towards high gain, low noise and high linearity amplifiers, increasing the difficulty of implementing various ADC architectures with traditional analog techniques. New applications that constantly demand better performance in terms of speed and accuracy, have created a need for energy-efficient ADCs in the GHz sampling frequency and low-to-moderate effective resolution range. The dominantly digital nature of Successive Approximation Register (SAR) ADCs makes them a good candidate for an energy-efficient and scalable design, overcoming the aforementioned challenges, but its sequential operation limits its applicability in the GHz sampling range. It is of great interest to systematically study and understand the trade-offs in realizing such multi-GS/s, low power ADCs.

This thesis work analyzes the trade-offs in realizing SAR ADCs in the GHz range in terms of speed, accuracy, power and area. First, basic ADC principles such as quantization and sampling are discussed and performance metrics are introduced. Then, the theory is summarized and the advantages and disadvantages of various types of ADC architectures for high speed operation are pointed out, while analysis and evaluation of system and circuit level techniques, in order to overcome the speed limitation of SAR ADCs, and extend their operation in the GHz sampling frequency with affordable power and area trade-offs follow. Based on the aforementioned analysis, a novel architecture is proposed to break the speed limit due to sequential operation, and realize an 8-bit single channel 2 GS/s SAR ADC. The proposed architecture combines optimally the multibit/ cycle approach with interleaving comparators. Furthermore, other techniques such as separating the sample and DAC functions, a segmentation switching capacitive DAC with sub-fF unit capacitors and a very lowpower reference generator contribute in speed enhancement and power reduction. The effectiveness and performance of the proposed architecture and techniques is verified through both behavioral modeling (MATLAB, Verilog-A) and transistor level circuit simulations. The sub-blocks composing the ADC such as comparators, DACs, T/H, reference buffers, preamplifiers, biasing blocks, clock drivers are designed in 40 nm digital LP CMOS process and simulation results both for individual blocks as well as for the whole ADC are presented. Simulation results indicate a sample rate of 2 GS/s with an SNDR of 41.8 dB at Nyquist input frequency (1 GHz) and above 35 dB until 10 GHz input frequency, while consuming a total power of 17.2mWat 1.2 V supply.


Receivers Topology Optimization of the Combined Active and WiFi-based Passive Radar Network

Presentation for the EuRAD14 conference

Inna Ivashko

This paper focuses on the accuracy analysis of the combined active and WiFi-based passive radar network. The Cramer-Rao Lower Bound is used as an accuracy metric. It is shown that localization performance of the active radar network can be improved with exploitation of the signals from passive bistatic WiFi radars. This makes reasonable to use information from passive and active radars simultaneously in order to enhance system localization capability. Sparsity-based algorithm is applied to find optimum geometry of the WiFi receivers at the fixed positions of the WiFi access points and active radars.

Additional information ...


EI Colloquium

Analog-to-digital converters

Jesper Steensgaard
Linear Technology, Milpitas, CA

Analog-to-digital converters have traditionally been a weak link in mixed-mode signal chains. As such, logarithmic and programmable-gain amplifiers have been used to effectively increase their overall dynamic range. In recent years, however, ADC performance has dramatically improved, making it difficult to design amplifiers and references capable of matching their performance. This talk will discuss the challenges of designing a circuit capable of driving a 20-bit SAR ADC with better than 1-part-per-million accuracy.

Biography

Jesper Steensgaard, obtained his MSEE and then his PhD from the Technical University of Denmark in 1999. He has 20+ years of experience in the design of high-resolution data converters. His early work focused on delta-sigma data converters, including mismatch-shaping binary-weighted-element DACs and continuous-time delta-sigma ADCs. Recently, Jesper developed a family of high-resolution low-power SAR ADCs, including the LTC2378-20, which combine the best features of delta-sigma ADCs (precision, low noise) and SAR ADCs (speed, low power, ease of use).


DIMES colloquium

Probabilistic Design for Reliability in Electronics and Photonics: Role, Attributes, Challenges

Prof.dr. Ephraim Suhir
Portland State University, USA

The recently suggested probabilistic design for reliability (PDfR) concept is based on:1) highly focused and highly cost-effective failure oriented accelerated testing (FOAT),aimed at understanding the physics of the anticipated failures and at quantifying, on the probabilistic basis, the outcome of FOATs conducted for the most vulnerable element(s) of the product of interest and the most likely and meaningful combination of possible stressors (the principle of superposition does not work in reliability engineering), and 2) simple and physically meaningful predictive modeling (PM), both analytical and computer-aided, aimed at bridging the gap between what one "sees" as a result of FOAT and what he/she will supposedly "get" in the field. FOAT and PM based sensitivity analysis (SA) algorithms are developed as by-products.

The PDfR concept is based on the recognition of the fact that nobody and nothing is perfect, and that the difference between a highly reliable and insufficiently reliable product is merely in the level of its probability of failure. If this probability (evaluated for the anticipated loading conditions and the given time in operation) is not acceptable, then such a SA can be effectively employed to determine what could be possibly changed, in terms of materials, geometries, application restrictions, etc., to improve the situation.

The PDfR analysis enables one also to check if the product is not "over-engineered", i.e., is not superfluously robust: if it is, it might be too costly: although the operational reliability cannot be low, it does not have to be higher than necessary either, but has to be adequate for the given product and application. This means that when both reliability and cost-effectiveness are imperative, ability to quantify reliability is a must. In this seminar the major PDfR concepts will be illustrated by case studies and practical examples. Although some advanced and subtle PDfR predictive modeling techniques have been recently developed for quantifying and assuring reliability of electronic and photonic products, especially those intended for aerospace applications, the practical examples addressed employ more or less elementary analytical models.

Biography

Prof. Dr. E. Suhir is Fellow of ASME, IEEE, American Physical Society (APS), Institute of Physics (UK), Society of Optical Engineers (SPIE), International Microelectronics and Packaging Society (IMAPS), Society of Plastics Engineers (SPE), Foreign Full Member (Academician) of the NAE, Ukraine, and Fulbright Scholar in Information Technologies. He has authored above 300 publications (patents, books, book chapters, papers) and received numerous professional awards, including 2004 ASME Worcester Read Warner Medal for outstanding contributions to the permanent literature of engineering and laying a foundation of a new discipline Structural Analysis in Electronics and Photonics Systems. Dr. Suhir is the third Russian American, after Steven Timoshenko and Igor Sikorsky, who received this prestigious award. Dr. Suhir is co-founder of the ASME Journal of Electronic Packaging and served as its Technical Editor for eight years (1994-2002).

Additional information ...


MEST welcome drink

Meet and greet your friends and colleagues with a FREE Drink to say Hallo !!!

Organized by MEST student association

Additional information ...


MSc ME Thesis Presentation

Long-range 3D Range Detector Based on Time-correlated Single-photon Counting

Dali Zhang

Three-dimensional (3D) range detectors enabling 3D computer vision is now popular in automotive industry. With their participation, automobile safety has been further enhanced, autonomous driving has become realizable. Time-correlated single-photon counting (TCSPC) technique utilizing complementary metal-oxide semiconductor (CMOS) single photon detectors (SPDs) and time-to-digital converters (TDCs) embodies the proper participant of automotive 3D vision, with low power consumption, low cost, high speed, high robustness, small size, and portability.

In this thesis, a TCSPC 3D range detector for automotive application was studied and modeled. The model covered all main components of a TCSPC system, including the TCSPC range detection process, the signal, and the noise. It was designed to predict the behavior of TCSPC systems and help future designers optimize the performance in accordance with the targeted application.

To verify the model, a experimental setup was designed, implemented, and characterized. The setup consists of a data acquisition system, data processing procedures, and an optical-mechanical system. Measurements performed using the setup have confirmed that the model was designed correctly. For further exploration, range detection from 0.2 m to 60 m were carried out.


PhD Thesis Defence

Multichannel Digital Silicon Photomultipliers for Time-of-Flight PET

Shingo Mandai

This thesis discusses the potential of CMOS based SiPMs, especially for TOF PET applications, in a systematic and comprehensive fashion. CMOS based SPADs are still need to be designed carefully to improve fill factor, TDCs be improved from the point of the area and power consumption, and the necessity of high voltage for SPADs be handled efficiently. Thus, this thesis also aims to design and integrate various circuits in the SiPM to realize the high integrations utilizing the biggest advantage of the CMOS technology.

Additional information ...


ISCAS 2014

2014 IEEE International Symposium on Circuits and Systems

Welcome from the General Chairs of the Organising Committee

On behalf of the Organising Committee we welcome you to Melbourne, ranked by the Economist Intelligence Unit in 2011, 2012 and 2013 as the most liveable City in the world, to Australia, and to the 2014 IEEE International Symposium on Circuits and Systems.

ISCAS2014 is sponsored by the Institute of Electrical and Electronic Engineers Circuits and Systems Society (IEEE CASS), and generously supported by the State Government of Victoria and the Melbourne Convention Bureau.

As you all know, ISCAS is the flagship annual conference of IEEE CASS, and it is well established as the worlds premier networking forum in the fields of theory, design and implementation of circuits and systems. As a result of the release of its 2012 Vision and Mission (see ieee-cas.org), the CASS goal is to develop ISCAS also as the leading forum for pioneering circuits and systems contributions to humanitys grand challenges.

Accordingly, the special theme of ISCAS 2014 is nano/bio circuits and systems applied to enhancing living and lifestyles, particularly in relation to the multidisciplinary grand challenges in healthcare and wellbeing, the environment and climate change.

Keynotes

ISCAS2014 has four keynote presentations, two of which address crucial aspects of high priority grand challenges, in health and in sustainability, while the other two describe frontier work at the extreme ends, in terms of scale, of circuits and systems engineering new devices that promise to sustain the remarkable advances in semiconductors that we have enjoyed for over 60 years, and design methods for systems of systems, which are relevant to so many grand challenge problems:

Dr Donald E. Ingber from Harvard University on Monday will present Microengineered Human Organs On Chips, describing advances he and his team have made in the engineering of microfluidic Organs-on-Chipsmicrochips lined by living human cells created with microfabrication techniques that recapitulate organ-level structure and functions as a way to replace animal testing for drug development and mechanistic discovery.

Professor Iven Mareels from The University of Melbourne in his talk on Wednesday, titled Circuits and Systems for Modern Irrigation Management, describes work over 15 years on circuits and systems research, development and commercialisation of an internet-of-things dedicated to smart irrigation water management.

Professor Victor Zhirnov from the Semiconductor Research Corporation, in Scaling Limits of Nanoionic Devices, elaborates how recognition that crystal defects could be used as controllable entities, rather than being seen as imperfections, leads to the possibility that nanoionic resistive switching devices may be scalable down to ~ 1nm and thus may offer a promising path to replace the foundation of todays computing technologies.

Dr. Stephan C. Stilkerich from Airbus Group will present Model Based Engineering of Highly Mobile Systems of Systems: Safe Aeroplanes; Safer Automobiles, with an introduction and post-talk discussion moderated by Dr Graham Hellestrand from Embedded Systems Technology. This keynote deals with front-line approaches to engineering electronic systems and their software, that are required to perform real-time control critical for the safe operation of airplanes and cars, including while operating in dense traffic and simultaneously reducing environmental impact.

Technical Program Regular Sessions

The technical program consists of tutorials, lecture papers, poster papers and demonstrations accepted based on peer review of the submission from regular open calls. We have retained many of the ISCAS features that have evolved in recent years, and added new features, some in response to ISCAS feedback, to continue to improve attendees experience of the event.

We are very pleased to report that ISCAS2014 will be first time that the new CASS Conference App will be made available to all attendees, and we look forward to your feedback to improve it. The CAS Society has supported the development of the Conference App, through Conference4Me, to facilitate the navigation of the conference agenda and venues, secure access to proceedings, micro-blogging, live discussion and ranking of papers, providing feedback to organizers and general improvement of attendees experience at CAS conferences.

Lecture papers follow the traditional ISCAS format. There are nine lecture sessions over three days, with session having 11 parallel streams. Sessions are 90 minutes with up to five papers, allowing 18 minute for each including introduction, presentation and discussion.

The Demonstration session and Poster sessions are held over 3 hours commencing at the 3pm coffee break on Monday, Tuesday and Wednesday. The Demonstration session is Monday only. There are no competing parallel lecture sessions during the first 90 minutes of each days Posters/Demonstrations, allowing increased attention to them from all attendees.

We have increased the length of the lunch break to 90 minutes. This will allow more time for the CASS side meetings, particularly the annual meetings of the 15 CASS Technical Committees, which are playing an increasingly important role in leadership of the Society. The longer break will also provide a more relaxed walk to the nearby restaurants for the lunch break, and we hope it will facilitate a greater level of networking.

Following the ISCAS2013 lead we continue the trial of offering free attendance at Tutorial and CAS-FEST sessions for all ISCAS2014 registrants. We have also expanded both the tutorial program and CAS-FEST. CASS goals in these moves are both to widen the reach of and to increase participation in the tutorial program and CAS-FEST. We will greatly appreciate feedback from attendees on the value you perceive in these offerings.

Tutorials

ISCAS2014 commences on Sunday with 19 half-day and 1 full-day Tutorial sessions.

We have included two Tutorial sessions on Technology Management in response to feedback from CASS industry members:

T19 Interfacing Organisations: How to successfully manage organizational interfaces by Felix Lustenberger; and T20 - Managing Technology Professionals by Tuna B. Tarim: Transitioning from Individual Contributor to Management. Felix and Tuna are CASS members and also leaders of IEEEs Technology Management Council, which was recently approved to transition to an IEEE Society.

Also in response to feedback, from the Women in CAS (WiCAS) and Young Professionals Program (formerly GoLD) groups, is a tutorial on career development, social skills, collaboration and networking:

T7 Engineering Networks that Work: Design Tools for Your Career by Dr Margaret Collins Margaret is a Cardiff-based research consultant, professional coach and trainer with extensive experience in helping people achieve their career goals. Come ready to get involved this is an active workshop session!

A third initiative in the Tutorials is a full day introduction to Memristive devices, circuits, systems and applications, the topic of this years CAS-FEST. This will cover all aspects of this emerging technology, namely: theory, practical nanodevices, physical switching mechanisms, circuits and emerging applications:

T21 If its Pinched its a memristor (AM), Professor Leon Chua T22 ReRAM Memristive Devices: Electrochemical Systems at the Atomic Scale (AM), Dr Ilia Valov T23 Analog and Mixed-Signal Applications of Memristive Devices (PM), Professor Dmitri Strukov T24 Integrating memristive devices in CMOS neuromorphic computing architectures (PM), Professor Giacomo Indiveri The aim of these sessions is to provide sufficient introduction to enable a typical ISCAS attendee to appreciate the state of the art material that will be presented in the CAS-FEST sessions.

CAS-FEST

Since its inception in 2010, the Circuits and Systems Forum on Emerging and Selected Topics has progressively become more closely integrated with ISCAS. This years topic was again selected from an open call and the winning proposal, from members of the Nonlinear Circuits and Systems (NCAS) Technical Committee, has taken still further this level of integration with ISCAS. This includes the presentation of invited introductory tutorials in the regular ISCAS Tutorials program (see above), the inclusion of three Special Sessions in the regular ISCAS Lecture Papers program, a full day of CAS-FEST Special Sessions on Wednesday, and the highlight full day of CAS-FEST Keynote talks on Thursday.

With this additional integration, CAS-FEST 2014 will bring together leading experts and provide a thorough coverage of the field of memristors, from an introduction to those unfamiliar with the field, through solidifying existing knowledge, to highlighting developments at the forefront of the field, and pointing to future challenges and promising directions for research. We hope that this coordinated approach will result in a landmark event in the development of the field.

Social Events and Awards Dinner

We are planning the now standard set of ISCAS evening events, with the Welcome Reception on Sunday evening soon after the conclusion of Tutorials, the WiCAS/YPP (formerly GoLD) event on early Monday evening, the Awards Dinner on Tuesday evening, and the Closing Reception immediately following the last session on Wednesday. Watch out for the Australian twists!

We hope that you will have a rewarding and enjoyable time in Melbourne at ISCAS2014 and look forward to meeting as many of you as we can!

Professor Jugdutt (Jack) Singh & Dr David Skellern General Co-Chairs, ISCAS 2014

Additional information ...


Lecture on ExG signal acquisition and processing electronics

Lecture on ExG signal acquisition and processing electronics

Wouter Serdijn

Wouter Serdijn will present the BELEM lecture on ExG signal acquisition and processing electronics

Additional information ...


EUCAP14 conference on antennas and propagation

Abstract submission: 13 Oct 2013

Conference dates: 6-8 April 2014

Application areas:

  • Fundamental research
  • Satcom on-the-move terminal antennas
  • Navigation, localisation, positioning and tracking
  • Cellular mobile communications (includes: base station, handheld devices)
  • Machine to machine, internet on devices
  • Wireless networks (includes: WLAN, indoor communication)
  • High data-rate transfer and backbone networks
  • RFID and sensor networks
  • Biomedical (includes: human body interaction, on-body antennas, electromagnetic exposure and interactions)
  • Satellite communications
  • Satellite passive and active remote sensing
  • RADAR
  • Radio astronomy
  • Signal and image processing
  • Defense and security
  • Short-range Giga-bit communications
  • Commercial software

Additional information ...
